The Bcl-2 inhibitor Obatoclax overcomes resistance to histone deacetylase inhibitors SAHA and LBH589 as radiosensitizers in patient-derived glioblastoma stem-like cells

This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

ABSTRACT

Glioblastoma has shown resistance to histone deacetylase inhibitors (HDACi) as radiosensitizers in cultures with Bcl-XL over-expression. We study the efficacy of SAHA/RTx and LBH589/RTx when manipulating Bcl-2 family proteins using the Bcl-2 inhibitor Obatoclax in patient-derived glioblastoma stem-like cell (GSC) cultures. GSC cultures in general have a deletion in phosphatase and tensin homolog (PTEN). Synergy was determined by the Chou Talalay method. The effects on apoptosis and autophagy were studied by measuring caspase-3/7, Bcl-XL, Mcl-1 and LC3BI/II proteins. The relation between treatment response and O6-methylguanine-DNA methyltransferase (MGMT) promoter methylation status, recurrence and gene expression levels of the tumors were studied. Obatoclax synergized with SAHA and LBH589 and sensitized cells to HDACi/RTx. Over 50% of GSC cultures were responsive to Obatoclax with either single agent. Combined with HDACi/RTx treatment, Obatoclax increased caspase-3/7 and inhibited Bcl-2 family proteins Bcl-XL and Mcl-1 more effectively than other treatments. Genes predictive for treatment response were identified, including the F-box/WD repeat-containing protein-7, which was previously related to Bcl-2 inhibition and HDACi sensitivity. We emphasize the functional relation between Bcl-2 proteins and radiosensitization by HDACi and provide a target for increasing responsiveness in glioblastoma by using the Bcl-2 inhibitor Obatoclax.

INTRODUCTION

Patients with glioblastoma have a poor prognosis.[1, 2] Thus far, maximally safe surgical resection and radiation therapy (RTx) with adjuvant temozolomide (TMZ) gives a median survival of 14.7 months.[3] The O6-Methylguanine-DNA methyltransferase (MGMT) promoter methylation status is the most important biomarker that predicts response to current therapy.[4] Some of the causes of poor outcome lie in the heterogeneity of the tumor and the multiple escape pathways glioblastoma harbors.[5, 6] Specifically targeting these resistance pathways using combination therapies can be an approach to achieve better treatment results. A novel therapy in glioblastoma is the epigenetic modulatory treatment with histone deacetylase inhibitors (HDACi). These drugs affect multiple pathways including apoptosis, autophagy and DNA damage repair.[7] We reported earlier that a subset of patient-derived glioblastoma stem-like cell cultures (GSC cultures) showed resistance to the combination of RTx with the HDACi SAHA or LBH589.[8] Both over-expression of Bcl-XL proteins as well as the maintained Bcl-2 proteins post-HDACi treatme nt were related to this resistance.[8] Thus, regulation of Bcl-2 family members may be an important mechanism in the resistance to HDACi as radiosensitizers. Others have already shown that these proteins are related to resistance to HDACi as single agents.[9] The Bcl-2 family members regulates the intrinsic cell death pathway by controlling permeability of the outer mitochondrial membrane.[10] In addition, by binding the endoplasmic reticulum, these proteins regulate autophagy by binding to Beclin-1.[11] Inhibiting these Bcl-2 family proteins may provide an effective strategy in overcoming resistance to HDACi.[12] A recent study has shown efficacy of the Bcl-2 inhibitor ABT-737 and SAHA in an immortalized glioma model. Efficacy was only observed in cell lines with an intact phosphatase and tensin homolog (PTEN) status. In our study, we aim to inhibit the anti-apoptotic Bcl-2 pathway by using Obatoclax, to enhance the efficacy of SAHA and LBH589 as both single agents and as radiosensitizers in the PTEN deleted patient-derived GSC model.[13, 14] Obatoclax is a Bcl-2 family inhibitor which has higher affinity than ABT-737 to inhibit Bcl-XL, Mcl-1 and to induce autophagy.[12, 15, 16] Obatoclax reduces Bak/Mcl-1-binding, up-regulates Bim and subsequently induces cytochrome-C release and caspase-3-activity.[17] The drug is currently being tested in clinical trials for hematological cancers, non-small cell lung carcinoma and extensive-stage small-cell lung carcinoma.[18-21] Our study provides novel insights into the efficacy of inhibiting the Bcl-2 family pathway by Obatoclax in overcoming resistance to HDACi as radiosensitizers. In addition, we identify gene expression prediction profiles for response to the various treatment modalities.

RESULTS

Patient-derived GSC cultures show differential sensitivity to Obatoclax

The IC₅₀ values of Obatoclax were determined in three patient-derived GSC cultures and in U373 glioma cells in order to find the right concentrations for further screening. Then, fourteen patient-derived glioblastoma cultures were screened for the combination treatments, after which validation of the results was performed in another five cultures. If the cultures were highly sensitive to Obatoclax, lower concentrations (10 and 30 nM) were used. Since the MGMT promoter methylation status is the most established predictive marker of glioblastoma survival[4], we evaluated whether treatment efficacy was related to this factor. Also we investigated the relation of response with recurrence status. Also, the relation between the IC₅₀ values and Bcl-2/Bcl-XL protein levels was investigated (Figure 1A-D, Table 1). The results show that Obatoclax reduced viability in the nanomolar range. The IC₅₀ values as approached by median effect equation, ranged from 17 – 562nM, varying per GSC culture. In total, eleven of nineteen GSC cultures had a methylated MGMT promoter status and seven cultures were derived from recurrent tumors. Neither of these parameters correlated to the IC₅₀ values of Obatoclax (p<0.05). The protein levels of these cultures were retrieved from previous research.[8] The protein levels were categorized as high or low. In cultures with high levels of Bcl-2, the mean IC₅₀ value is significantly higher than in other cultures (p=0.017). For Bcl-XL, we observed a trend that higher IC₅₀ values occurred in cultures with lower Bcl-XL protein levels (p=0.09).

Obatoclax synergizes with HDAC inhibitors culture-dependently in patient-derived GSC cultures

To determine synergy between Obatoclax and the HDACi SAHA or LBH589, the Chou Talalay method was used in the patient-derived GSC cultures GS79 and GS257. Next, the panel of fourteen and five patient-derived GSC cultures were screened with the previously mentioned concentrations of Obatoclax, combined with SAHA and LBH589, and with or without RTx. Also, the MGMT promoter methylation and recurrence status of the tumors were related to responses to treatment. For both cultures GS79 and GS257, Obatoclax showed synergistic effects with SAHA and LBH589 with combination indices < 1 (Figure 2A). The combination efficacy widely varied in the panel of patient-derived GSC cultures: responders and non-responders were identified for all combination treatments (Table 1, Figure 3). In the first set of glioblastoma cultures (n=14) eight cultures responded to SAHA/Obatoclax treatment. In the validation set (n=5) four cultures responded to treatment. Enhancement factors ranged from 1.2 – 14.3 with effect sizes ranging from 5% - 35%. Seven of the fourteen cultures responded to LBH589/Obatoclax treatment and three of the five cultures in the validation set responded to treatment. The enhancement factors ranged from 0.9 – 4.9 with effect sizes of -6% – 26%. Obatoclax sensitized seven of fourteen GSC cultures to radiation, and all the GSC cultures in the validation set responded to this treatment. The enhancement factors ranged from 0.9–3.6 with effect sizes ranging from -5% – 26%. The MGMT promoter methylation and recurrence status were not related to the effect sizes of the tested combination treatments (p>0.05) (Figure 2B).

Obatoclax overcomes resistance to HDAC inhibitors as radiosensitizers in patient-derived GSC cultures

To evaluate whether treatment with Obatoclax sensitizes patient-derived GSC cultures to HDACi as radiosensitizers, the nineteen patient-derived GSC cultures were evaluated (Figure 2C). The co-treatment with Obatoclax resulted in a significant reduction in cell viability compared to the combination treatment of RTx and SAHA without Obatoclax. However the effect sizes of triple treatment were small, since the ATP-levels at day eight show that either HDACi/Obatoclax, Obatoclax/RTx or HDACi/RTx already inhibited the largest part of the cell population. In the patient-derived GSC cultures GS257, GS274, GS224 and GS401, the effect sizes ranged from 5- 9% and the enhancement factor ranged from 1.1 – 2.2 (GS257 and GS274 shown in Figure 2C). The addition of Obatoclax to the combination treatment of LBH589/RTx did not result in significant additional treatment effects.

Obatoclax triggers apoptosis and induces autophagy in both HDAC inhibitor and HDACi/RTx combination treatment

The CellTiter-Glo assay at day eight may have underestimated the effects of triple treatment due to the lack of differentiation between the effective treatments at this time point. We hypothesized that early treatment differences could be observed by studying the important cell death mechanisms of the Bcl-2 pathway: apoptosis and autophagy.[22] We studied early caspase-3/7 activation, which could provide more insights into the difference in efficacy between triple and combination treatment. The activated caspase-3/7 levels were monitored over time for SAHA concentrations at which additional effects were observed after triple treatment in the viability assay. The HDACi SAHA and the Bcl-2 family inhibitor Obatoclax activated the caspase-3/7 activity at both 48 and 60 hours post-treatment (Figure 4A). There was no additional caspase-3/7 activation in case of the combination treatment of SAHA and RTx, in comparison to single agents alone. Combination treatment of RTx/Obatoclax did not increase caspase-3/7 activity in comparison to single agent treatment either. In both SAHA/Obatoclax and SAHA/Obatoclax/RTx treated cells, increased caspase-3/7 activity was observed at 48 and 60 hours (p<0.05), with SAHA/Obatoclax/RTx being significantly more effective than SAHA/Obatoclax (p<0.05). As well as inducing caspase-dependent apoptosis, the Bcl-2 family proteins play a crucial role in autophagy and autophagosome formation which can be studied by conversion of LC3BI/II proteins. Treatment of GS257 cells with either SAHA, RTx and SAHA/RTx did not result in conversion of LC3I/LC3II at 48 and 72 hours post-treatment (Figure 4B). On the contrary, treatment with Obatoclax strongly induced autophagy at 48 hours post-treatment. Obatoclax increased both LC3I and LC3II in combination with RTx. In the SAHA/Obatoclax and Obatoclax/SAHA/RTx treated cells, LC3BI/II conversion (LC3II divided by LC3I) was observed at both 48 and 72 hours post-treatment. The triple treatment showed a higher ratio of LC3BI/II conversion.

Obatoclax combined with HDACi and HDACi/RTx effectively decreases Bcl-XL and Mcl-1

As increased autophagy and apoptosis were observed in both the combination and triple treatment, we related these effects to altered levels of the anti-apoptotic Bcl-2 proteins Bcl-XL and Mcl-1 in the patient-derived glioblastoma culture GS257 (Figure 4C). The protein levels of Bcl-XL were decreased by Obatoclax at 48 hours post-treatment, but after 72 hours the levels were similar to controls. The HDACi SAHA even induced Bcl-XL protein levels at 48 hours, whereas at 72 hours, these levels were again similar to controls. The combination treatments of SAHA/RTx and Obatoclax/RTx did not affect Bcl-XL protein levels, whereas SAHA/Obatoclax and SAHA/Obatoclax/RTx completely eliminated Bcl-XL protein levels after both 48 and 72 hours. For Mcl-1, the most important effects were observed 48 hours after RTx: the levels were decreased by Obatoclax/RTx, Obatoclax/SAHA and to a larger extent by Obatoclax/SAHA/RTx. All these treatments induced additional Mcl-1 bands on the Western blot at both 37kDa and 25 kDa. The Mcl-1 protein levels (37 and 40 kDa) of cells treated by the latter two treatments were relatively low compared to the other combination treatments at 72 hours. In addition, the two additional Mcl-1 bands were induced by these treatments at both 15 and 17 kDa. These bands may correspond to cleaved Mcl-1, which has been associated with activation of apoptosis.

Levels of specific genes correlate with response of GSC cultures to combination treatments with Obatoclax

In order to identify predictive markers for treatment response, the gene expression levels of the original tumor were related the treatment response of the fourteen patient-derived GSC cultures. The quality assessment of the gene expression array data showed that data of thirteen samples could be used for the analysis (GS102 was excluded). The validation of the identified genes that correlated with treatment response was performed in an independent set of five patient-derived GSC cultures. This resulted in a specific set of genes of which levels were related to treatment response in both the initial and validation set. For selection, at least a 1.5-fold change (log-2 scale) was the minimum difference in gene expression between the most and the least responsive patient-derived glioblastoma culture. The functions of the identified genes were analyzed using the QIAGEN’s Ingenuity® Pathway Analysis. We focused on the functions and networks of the genes which were associated with the combination responses. Table 2A shows the gene lists per treatment, the correlation coefficient with the treatment effects and the fold-change difference in gene expression levels between the most and least sensitive corresponding glioblastoma culture. The responses to LBH589/Obatoclax treatment were related to gene expression levels of ten genes, being the non-coding RNA NCRNA00086, transmembrane protease serine 3 (TMPRSS3), proto-cadherin gamma-subfamily B6 (PCDHGB6), small integral membrane protein 21 (LOC284274 or SMIM21), forkhead box K1 (LOC642782 or FOXK1), vasoactive intestinal peptide (VIP), zinc finger and SCAN domain containing 23 (ZSCAN23), F-box and WD repeat domain containing 7, E3 ubiquitin protein ligase (FBXW7), microRNA 325 (MIR325), and G protein-coupled receptor 52 (GPR52) (Figure 5A,D). This set genes were found to be functioning in processes of cell cycle (FBXW7, VIP, FOXK1), cell death and survival (VIP, FBXW7, PCDHGB6) and cell morphology (FBXW7, VIP) as top three gene functions (Table 2B). Another group recently showed that mutations in FBXW7 were related to SAHA-induced cell death and Bcl-2 inhibition.[12] The genes that were related to responses to Obatoclax/RTx treatment were ST6 (alpha-N-acetyl-neuraminyl-2,3-beta-galactosyl-1,3)-N-acetylgalactosaminide alpha-2,6-sialyltransferase 5 (ST6GALNAC5), EGF-like, fibronectin type III and laminin G domains (EGFLAM), ABI family member 3 (NESH) binding protein (ABI3BP), beta-carotene oxygenase 1 (BCO1) and DIRAS family GTP-binding RAS-like 1 (DIRAS1) (Figure 5B,E). These genes were involved in cellular development and cellular growth and proliferation (DIRAS1), as well as lipid metabolism (BCO1, ST6GALNAC5). Moreover, all the five genes were found to function in the same network, namely a cell cycle network (Table 2B). The responses to SAHA/Obatoclax treatment were related to one gene, namely ubiquilin 1 (UBQLN1) (Figure 5C). This gene is involved in cell morphology, cellular compromise and cell death and survival according to the functional analysis. In summary, we present a number of genes that is related to the responses of patient-derived GSC cultures to combination treatments with Obatoclax, RTx and HDACi. Functional analysis showed that most of these genes were related to cell regulatory aspects including cell death and survival, as well as cycle regulatory processes.

DISCUSSION

The present study emphasizes the efficacy of the Bcl-2 family pathway inhibition by Obatoclax in sensitizing patient-derived GSC cultures to HDACi/RTx, and hereby provides a circumvention for a tumor-related resistance mechanism to treatment. The Bcl-2 family proteins are heterogeneously expressed in glioblastoma as about 30%[23] to 60%[24] shows over-representation of these proteins.[24-26] Moreover, Bcl-XL levels in patient-derived GSC cultures have shown a relationship with resistance to HDACi/RTx response.[8] Here, we demonstrate that Obatoclax acted synergistically with HDACi and show efficacy in a large set of patient-derived glioblastoma cultures. Hereby we confirm that this pathway is an adequate target to obtain treatment responses. The use of the serum-free patient-derived GSC culture model allowed to study resistance and tumor response mechanisms in a more representative manner than in immortalized glioma cell lines.[13] Importantly, this model provides a tool to develop predictive profiles of treatment response. The efficacy of down-regulation of Bcl-2 and Bcl-XL in inducing spontaneous cell death was already shown before.[27] This efficacy depended on neither MGMT promoter methylation status nor recurrence. A number of genes was found to be related to treatment response of patient-derived GSC cultures to combination treatments. Others showed that the gene FBXW7 was related to SAHA-induced cell death and Bcl-2 inhibition.[12] This points to a biological rationale in Mcl-1 functioning to be predictive of treatment response to LBH589/Obatoclax. The use of these genes as potential markers for patient stratification or the functionality of these genes in sensitivity to combination treatments should be explored in future studies.

Others have studied the relationship between HDACi and Bcl-2 family proteins before. A recent study has shown that the intact PTEN immortalized malignant glioma cell lines are susceptible to the combination of SAHA and the Bcl-2 inhibitors ABT-737, whereas PTEN mutations were not.[28] They also showed that inhibition of the PTEN/PI3K pathway by BKM-120 sensitized glioma cells for ABT-737.[29] The patient-derived GSC model we used in this study is known to harbor PTEN deletions due to loss of chromosome 10q [13, 14], and ensures that we tested the treatment efficacy in a setting of hyper-activation of the PIK3-pathway. Therefore, this suggests that Obatoclax is a more potent combination partner for HDACi in PTEN deleted tumors than ABT-737. The main differences between Obatoclax and ABT-737 are the stronger induction of autophagy[16] and the stronger inhibition of Mcl-1 by the first drug. Both can be underlying the efficacy in PTEN deleted tumors.[15] Earlier, the efficacy of SAHA was related to Mcl-1 levels in acute myeloid leukemia.[30] Another study showed that in diffuse large B-cell lymphoma, over-expression of Bcl-2 and Bcl-XL triggered resistance to the HDACi SAHA and Trichostatin A, whereas the Bcl-2 family inhibitor ABT-737 increased sensitivity to SAHA treatment. Also, this study showed that the least sensitive cells to SAHA showed up-regulation of Bcl-XL and Mcl-1 proteins.[31] The loss of pro-apoptotic Bcl-2 family proteins Bax or Bax/Bak ratios are related to insensitivity to HDACi in Burkitt’s lymphoma in a predictive and functional sense.[32] In mantle cell lymphoma, the efficacy of SAHA was enhanced by the BH-3 mimetic ABT-263.[33] In contrast, another study did not find HDACi efficacy to be related to Bcl-2 family proteins.[31] Thus, these relationships between Bcl-2 family proteins and HDACi responses are either tumor type or HDACi specific. Our study shows that inhibition of the Bcl-XL and Mcl-1 proteins by Obatoclax is related to efficacy of SAHA alone or in combination with RTx. We observed restored levels of Bcl-2 family proteins Bcl-XL and Mcl-1, occurring at 72 hours after Obatoclax, HDACi and HDACi/RTx treatments. This observation indicates that Bcl-2 family members are restored within this time frame, if these are not inhibited effectively. This in turn can contribute to resistance to treatment.

As a mechanism of action, HDACi have shown to be able to down-regulate Bcl-2 family members, however not in all heterogeneous tumors including glioblastoma.[34] Others suggest that the up-regulation of pro-apoptotic members by HDACi are neutralized by high levels of anti-apoptotic members such as Bcl-2 and Bcl-XL.[35] In squamous cell carcinoma Mcl-1 was related to resistance to the BH3-mimetic ABT-737. The HDACi SAHA has the ability to synergize with this drug by shuttling the Bcl-2 family protein Bim from Mcl-1 to Bcl-2/Bcl-XL.[12]

Not only does Obatoclax enhance the efficacy of HDACi/RTx, it also enhanced the efficacy of RTx as treatment alone. Thus, in many treatment modalities, including conventional glioblastoma treatment such as RTx, the Bcl-2 family members may play a crucial role. Others have shown already that Bcl-2 family members are determinants of responsiveness to treatment in glioblastoma. Bcl-XL levels were related to radioresistance in glioma [36] and Mcl-1 proteins regulate temozolomide efficacy in glioma independently of MGMT promoter methylation status.[37] Here, we found that MGMT promoter methylation status and tumor recurrence, which normally determine patient overall outcome[4], were not related to the applied treatments either. Thus, our results are unlikely to be determined by these tumor statuses a priori.

The effect sizes of both SAHA and LBH589 in combination with Obatoclax correlated to expression levels of specific genes. Gene profiles may provide an opportunity to include predictive decision variables in treatment and patient selection. This may be of clinical relevance specifically for the MGMT un-methylated tumors. We need to point out immediately that these gene sets need further exploration in in vivo settings to be validated. Although these gene sets do not necessarily implicate mechanisms of action of the proposed treatments, they may provide insight into resistance mechanisms. FBXW7, the gene associated with LBH589/Obatoclax response, was shown to have a relationship with response to SAHA before, as well as to Bcl-2 inhibition. Both FBXW7 and Bcl-2 inhibition were predictive for efficacy of SAHA in squamous cell carcinoma. Mutated FBXW7 sensitized cells to HDACi and stabilized Mcl-1.[12] FBXW7 encodes for the protein ubiquitin protein ligase and is positively related with the effect size of LBH589/Obatoclax in our study. Obatoclax has the potency to inhibit Mcl-1, and is more effective in combination with LBH589 in tumors that highly express FBXW7. Moreover, the whole gene set which was related to LBH589/Obatoclax response was associated with cell cycle and cell death and survival mechanisms, represented by the four genes FBXW7, VIP, FOXK1 and PCDHGB6. This was also true for the gene ubiquilin 1 (UBQLN1), which was associated to SAHA/Obatoclax response. This gene functions in cell death and survival as well. In addition, response to RTx/Obatoclax was associated to genes that function in the cell cycle and cellular proliferation as well. Basic studies should be performed to assess the direct relationship between the function of these genes and the success rate of Obatoclax, but the genes provide insights into the process of cellular responses. Our data on cell regulation by caspase-3/7 and autophagy are therefore potentially important mechanisms of action in the response to combination treatment.

In summary, this study underlines the potential of inhibiting the Bcl-2 family proteins in combination treatment with HDACi and HDACi/RTx. Potential toxicities of combination therapies which may limit clinical use should be explored further. Examples could be thrombocytopenia by inhibition of Bcl-XL[38] and HDACi.[39] Furthermore, we obtained predictive gene profiles that are associated with cellular regulatory functions for the combination treatments with Obatoclax. These gene sets may aid in selecting the tumors most responsive to treatment.

MATERIALS & METHODS

Chemicals

Stocks of 50mM SAHA (Cayman chemicals, MI, USA), 200μM LBH589 (Biovision, CA, USA) and 60mM Obatoclax (Selleck Chemicals, Texas, USA) were prepared in dimethyl sulfoxide (DMSO, Sigma-Aldrich, MO, USA) and stored at -20°C. Staurosporin was obtained from BioMol, Germany.

Patient-derived glioblastoma stem-like cell cultures

Fresh glioblastoma tissue was obtained from patients undergoing surgery at the Department of Neurosurgery, ErasmusMC (Rotterdam, The Netherlands) after informed consent and approval by the institution’s medical ethical board. The tissue was dissociated mechanically and enzymatically, after which the patient-derived GSC cultures were cultured under serum-free conditions in DMEM/F12 medium supplemented with 2% B27 (Life Technologies, UK), 20ng/ml bFGF, 20ng/ml EGF (Tebu-Bio, France), 5ug/ml heparin (Sigma-Aldrich, MO, USA) as was described previously.[13] These patient-derived GSC cultures, which were characterized and validated as previously reported.[13] The U373 cells were cultures under 10% serum conditions in DMEM medium. The cultures were stored at 37 °C in a humid 95% air/5% CO₂ chamber. In total, nineteen patient-derived GSC cultures were used for the experiments.

Viability assay

Concentration-response assays were performed in order to determine IC₅₀ values of Obatoclax. The cells of various GSC cultures were plated at 1x10³ cells/well in 96-wells plates. After incubation overnight, various drug concentrations in three-fold increments were applied to the cells. At five and eight days post-treatment cell viability was measured using the CellTiter-Glo assay (Promega, WI, USA). The results were plotted and the IC₅₀ values were computed using the median effect equation.[41] The IC₅₀ values of the HDACi SAHA and LBH59 in the GSC cultures GS79 and GS257 were derived from previous research.[8] Subsequently, Chou-Talalay assays were performed on the GSC cultures GS79 and GS257 for Obatoclax in combination with the HDACi to determine synergy.[40] After assessment of the combination effects in these two cultures, either two or four concentrations (10, 30, 100 and 225nM) were applied to the panel of patient-derived GSC cultures to determine the combination effects. From these concentrations, an estimated IC₅₀ was calculated for each glioblastoma culture. The HDACi concentrations were always kept similar at 1μM SAHA and 20nM LBH589. The DMSO concentration was never above 1% in the dilutions. RTx (3Gy) was applied as single-fraction treatment from a Cesium-137 source 24 hours after drug application.

Western blot

Alteration of specific proteins post-treatment was determined by seeding cells of the GSC culture GS257 in culture flasks with 225nM Obatoclax, 1 µM SAHA and the combination. After 24 hours, the cells were irradiated with 3Gy. At 24 and 48 hours post-RTx, the cells were harvested, washed with PBS and collected in a 1% Triton-X100 (Sigma-Aldrich) buffer for protein isolation. Protein concentrations were measured with the BCA Protein Assay Reagent Kit (Thermo Fisher Scientific, MA, USA). Protein separation was performed on a 4-15% pre-casted gel (Bio-Rad, CA, USA), and blotted onto a PVDF membrane (Immobilon-P, Millipore, MA, USA) using the Mini-Protean Tetra Cell system (Bio-Rad). After blocking the membranes with 5% non-fatty milk solution for 30 minutes at room temperature, the blots were incubated with primary antibodies against Bcl-XL, LC3BI/II, Mcl-1 (1:375, Cell Signalling, MA, USA) and anti-β-actin (1:5,000, Millipore) in 5% BSA/TBS-T overnight. Membranes were washed with TBS-T 0.2% and incubated with secondary antibodies, anti-rabbit-HRP and anti-mouse-HRP (1:2000, Dako Denmark A/S, Denmark) 1½h at room temperature and detected by chemiluminescence using the Pierce ECL substrate (Thermo Fisher Scientific) and the ChemiDoc MP system (BioRad). The data were analyzed using the ImageLab software (Bio-rad).

Caspase-3/7 assay

The GS257 GSC cultures were seeded at 5x10³ cells/well in a black 96-wells plate and incubated with the treatment as performed in the viability and Western blot experiments (SAHA, Obatoclax, after 24 hours RTx). Immediately after RTx, the cells were incubated with 5μM of the kinetic apoptosis reagent of the CellPlayer 96-Well Kinetic Caspase-3/7 Apoptosis Assay (Essen Bioscience) and were live imaged by using the IncuCyte system (Essen BioScience) with a 10X objective at 37°C in a humid 95% air/5% CO₂ chamber. The apoptosis-inducer staurosporin (20nM) was used as a positive control. Three fluorescent images/well were collected up to 60 hours post-RTx. The caspase-3/7 activity was presented as counted objects/mm² as measured by the IncuCyte software.

Gene expression analysis

The RNA of the original glioblastoma tissue corresponding with the glioblastoma cultures was isolated with the RNeasy Mini kit (#74104, Qiagen Inc., CA, USA). The mRNA expression levels of were analysed by the HumanHT-12 v4 Expression BeadChip microarray (Illumina, CA, USA). The raw intensity values of all the samples were normalized using quantile normalization with the Partek software, version 6.6 (Partek Inc., St. Louis, MO, USA). Subsequently, the Partek Batch Remover was used to remove the effect of the differences between the batches. The effect sizes of HDACi/Obatoclax, and RTx/Obatoclax in n=13 GSC cultures (mRNA expression data of GS102 did not meet quality standards) were correlated to the gene expression levels. The data were analyzed using the linear model function in R package ‘stats’ (version 2.15.3) to identify genes that correlate to treatment responses (Pearson’s R correlations). The p-values were adjusted for multiple comparisons using the method of Benjamini & Hochberg.[41] The cut-off values for significantly expressed genes were the adjusted p-values (p<0.05). The initially identified genes that significantly correlated with response were validated using a sample set of five additionally treated GSC cultures (p<0.05). Heat maps of the genes were constructed by the OmniViz Treescape software. The functional and network analyses of the identified genes were performed using the QIAGEN’s Ingenuity® Pathway Analysis (IPA®, QIAGEN Redwood City, http://www.qiagen.com/ingenuity).

Quantitative PCR on MGMT promoter methylation

The DNA of the various patient-derived GSC cultures was isolated and 100ng was used for the quantitative polymerase chain reaction (PCR). The DNAsamples were modified with sodium bisulphite using the EZ DNA Methylation GoldTM kit (Zymo Research, Baseclear, The Netherlands) Primers specific for methylated and un-methylated MGMT promoter DNA were used as described by others.[42] Methylation specific primers were F: TTTCGACGTTCGTAGGTTTTCGC and R: GCACTCTTCCGAAAACGAAACG. The un-methylated specific primers were F: TTTGTGTTTTGATGTTTGTAGGTTTTTGT and R: AACTCCACACTCTTCCAAAAACAAAACAQ. The PCR conditions were used as described by others[43], with annealing temperature of 59ºC and 40 cycles of amplification yielding PCR products for methylated and un-methylated DNA of 80 and 93 base pairs, respectively. The PCR products were separated on a routine 2% agarose gel. As a methylated control the DNA isolated from FFPE human colorectal cancer cell line SW48 was used and FFPE human tonsil DNA was used as an un-methylated control. In addition, in each experiment a H₂ O sample without DNA was used as a negative contamination control.

Statistical analysis

For the viability and caspase-3/7 assay experiments, the means of triplicates were plotted with the standard deviations. The Western blots were performed in singlicate. The results were presented as a percentage of non-treated controls. The differences between treatment effects were analyzed using the one-way ANOVA and the Tukey Post-Test for multiple conditions. The statistical significance was defined as p<0.05. The differences in mean cell viability between combinations were presented as effect sizes. In addition, we calculated the enhancement factor of combination treatments, as was described by Chou.[44] In case of an enhancement factors > 1 in combination with p<0.05, the combination was considered effective and the GSC was defined as a responder.

• 1. DeAngelis LM. Brain tumors. N Engl J Med. 2001; 344(2):114-123. [PubMed]
• 2. Stupp R, Mason WP, van den Bent MJ, Weller M, Fisher B, Taphoorn MJ, Belanger K, Brandes AA, Marosi C, Bogdahn U, Curschmann J, Janzer RC, Ludwin SK, Gorlia T, Allgeier A, Lacombe D, et al. Radiotherapy plus concomitant and adjuvant temozolomide for glioblastoma. The New England journal of medicine. 2005; 352(10):987996. [PubMed]
• 3. Stupp R, Hegi ME, Mason WP, van den Bent MJ, Taphoorn MJ, Janzer RC, Ludwin SK, Allgeier A, Fisher B, Belanger K, Hau P, Brandes AA, Gijtenbeek J, Marosi C, Vecht CJ, Mokhtari K, et al. Effects of radiotherapy with concomitant and adjuvant temozolomide versus radiotherapy alone on survival in glioblastoma in a randomised phase III study: 5-year analysis of the EORTC-NCIC trial. Lancet Oncol. 2009; 10(5):459-466. [PubMed]
• 4. Hegi ME, Diserens AC, Godard S, Dietrich PY, Regli L, Ostermann S, Otten P, Van Melle G, de Tribolet N and Stupp R. Clinical trial substantiates the predictive value of O-6-methylguanine-DNA methyltransferase promoter methylation in glioblastoma patients treated with temozolomide. Clin Cancer Res. 2004; 10(6):1871-1874. [PubMed]
• 5. Thaker NG and Pollack IF. Molecularly targeted therapies for malignant glioma: rationale for combinatorial strategies. Expert Rev Neurother. 2009; 9(12):1815-1836. [PubMed] https://doi.org/10.1586/ern.09.116.
• 6. Hegi ME, Sciuscio D, Murat A, Levivier M and Stupp R. Epigenetic deregulation of DNA repair and its potential for therapy. Clin Cancer Res. 2009; 15(16):5026-5031. [PubMed]
• 7. Li Z and Zhu WG. Targeting Histone Deacetylases for Cancer Therapy: From Molecular Mechanisms to Clinical Implications. International journal of biological sciences. 2014; 10(7):757-770. [PubMed] https://doi.org/10.7150/ijbs.9067.
• 8. Berghauser Pont LM, Naipal K, Kloezeman JJ, Venkatesan S, van den Bent M, van Gent DC, Dirven CM, Kanaar R, L MM and Leenstra S. DNA damage response and antiapoptotic proteins predict radiosensitization efficacy of HDAC inhibitors SAHA and LBH589 in patient-derived glioblastoma cells. Cancer Lett. 2014.
• 9. Lee JH, Choy ML and Marks PA. Mechanisms of resistance to histone deacetylase inhibitors. Advances in cancer research. 2012; 116:39-86. [PubMed]
• 10. Dewson G, Kluck, R.M. Bcl-2 family-regulated apoptosis in health and disease. Cell Health and Cytoskeleton. 2010; 2:9-22.
• 11. Pattingre S, Tassa A, Qu X, Garuti R, Liang XH, Mizushima N, Packer M, Schneider MD and Levine B. Bcl-2 antiapoptotic proteins inhibit Beclin 1-dependent autophagy. Cell. 2005; 122(6):927-939. [PubMed]
• 12. He L, Torres-Lockhart K, Forster N, Ramakrishnan S, Greninger P, Garnett MJ, McDermott U, Rothenberg SM, Benes CH and Ellisen LW. Mcl-1 and FBW7 control a dominant survival pathway underlying HDAC and Bcl2 inhibitor synergy in squamous cell carcinoma. Cancer discovery. 2013; 3(3):324-337. [PubMed] https://doi.org/10.1158/2159-8290.CD-12-0417.
• 13. Balvers RK, Kleijn A, Kloezeman JJ, French PJ, Kremer A, van den Bent MJ, Dirven CM, Leenstra S and Lamfers ML. Serum-free culture success of glial tumors is related to specific molecular profiles and expression of extracellular matrix-associated gene modules. Neuro Oncol. 2013; 15(12):1684-1695. [PubMed] https://doi.org/10.1093/neuonc/not116.
• 14. Chen R, Nishimura MC, Bumbaca SM, Kharbanda S, Forrest WF, Kasman IM, Greve JM, Soriano RH, Gilmour LL, Rivers CS, Modrusan Z, Nacu S, Guerrero S, Edgar KA, Wallin JJ, Lamszus K, et al. A hierarchy of selfrenewing tumor-initiating cell types in glioblastoma. Cancer Cell. 2010; 17(4):362-375. [PubMed]
• 15. Nguyen M, Marcellus RC, Roulston A, Watson M, Serfass L, Murthy Madiraju SR, Goulet D, Viallet J, Belec L, Billot X, Acoca S, Purisima E, Wiegmans A, Cluse L, Johnstone RW, Beauparlant P, et al. Small molecule obatoclax (GX15070) antagonizes MCL-1 and overcomes MCL-1-mediated resistance to apoptosis. Proc Natl Acad Sci U S A. 2007; 104(49):19512-19517. [PubMed] https://doi.org/10.1073/pnas.0709443104.
• 16. Wroblewski D, Jiang CC, Croft A, Farrelly ML, Zhang XD and Hersey P. OBATOCLAX and ABT-737 induce ER stress responses in human melanoma cells that limit induction of apoptosis. PLoS One. 2013; 8(12):e84073. [PubMed] https://doi.org/10.1371/journal.pone.0084073.
• 17. Trudel S, Li ZH, Rauw J, Tiedemann RE, Wen XY and Stewart AK. Preclinical studies of the pan-Bcl inhibitor obatoclax (GX015-070) in multiple myeloma. Blood. 2007; 109(12):5430-5438. [PubMed]
• 18. Health UNIo. (accessed 14.08.08). www.clinicaltrials.gov.. 2007; 109(12):5430-5438. [PubMed]
• 19. Chiappori AA, Schreeder MT, Moezi MM, Stephenson JJ, Blakely J, Salgia R, Chu QS, Ross HJ, Subramaniam DS, Schnyder J and Berger MS. A phase I trial of panBcl-2 antagonist obatoclax administered as a 3-h or a 24-h infusion in combination with carboplatin and etoposide in patients with extensive-stage small cell lung cancer. Br J Cancer. 2012; 106(5):839-845. [PubMed] https://doi.org/10.1038/bjc.2012.21.
• 20. Oki Y, Copeland A, Hagemeister F, Fayad LE, Fanale M, Romaguera J and Younes A. Experience with obatoclax mesylate (GX15-070), a small molecule pan-Bcl-2 family antagonist in patients with relapsed or refractory classical Hodgkin lymphoma. Blood. 2012; 119(9):2171-2172. [PubMed]
• 21. Goard CA and Schimmer AD. An evidence-based review of obatoclax mesylate in the treatment of hematological malignancies. Core evidence. 2013; 8:15-26. [PubMed] https://doi.org/10.2147/CE.S42568.
• 22. Yu L and Liu S. Autophagy contributes to modulating the cytotoxicities of Bcl-2 homology domain-3 mimetics. Seminars in cancer biology. 2013; 23(6 Pt B):553-560. [PubMed]
• 23. Tirapelli LF, Bolini PH, Tirapelli DP, Peria FM, Becker AN, Saggioro FP and Carlotti Jr CG. Caspase-3 and Bcl-2 expression in glioblastoma: an immunohistochemical study. Arquivos de neuro-psiquiatria. 2010; 68(4):603-607. [PubMed]
• 24. Kraus JA, Wenghoefer M, Glesmann N, Mohr S, Beck M, Schmidt MC, Schroder R, Berweiler U, Roggendorf W, Diete S, Dietzmann K, Heuser K, Muller B, Fimmers R, von Deimling A and Schlegel U. TP53 gene mutations, nuclear p53 accumulation, expression of Waf/p21, Bcl-2, and CD95 (APO-1/Fas) proteins are not prognostic factors in de novo glioblastoma multiforme. J Neurooncol. 2001; 52(3):263-272. [PubMed]
• 25. Cartron PF, Loussouarn D, Campone M, Martin SA and Vallette FM. Prognostic impact of the expression/phosphorylation of the BH3-only proteins of the BCL-2 family in glioblastoma multiforme. Cell death & disease. 2012; 3:e421. [PubMed] https://doi.org/10.1038/cddis.2012.150.
• 26. Abdullah JM, Ahmad F, Ahmad KA, Ghazali MM, Jaafar H, Ideris A, Ali AM, Omar AR, Yusoff K, Lila MA and Othman F. Molecular genetic analysis of BAX and cyclin D1 genes in patients with malignant glioma. Neurological research. 2007; 29(3):239-242. [PubMed]
• 27. Jiang Z, Zheng X and Rich KM. Down-regulation of Bcl-2 and Bcl-xL expression with bispecific antisense treatment in glioblastoma cell lines induce cell death. J Neurochem. 2003; 84(2):273-281. [PubMed]
• 28. Foster KA, Jane EP, Premkumar DR, Morales A and Pollack IF. Co-administration of ABT-737 and SAHA induces apoptosis, mediated by Noxa upregulation, Bax activation and mitochondrial dysfunction in PTEN-intact malignant human glioma cell lines. J Neurooncol. 2014. [PubMed]
• 29. Jane EP, Premkumar DR, Morales A, Foster KA and Pollack IF. Inhibition of phosphatidylinositol 3-kinase/AKT signaling by NVP-BKM120 promotes ABT-737induced toxicity in a caspase-dependent manner through mitochondrial dysfunction and DNA damage response in established and primary cultured glioblastoma cells. J Pharmacol Exp Ther. 2014; 350(1):22-35. [PubMed] https://doi.org/10.1124/jpet.114.212910.
• 30. Pierceall WE, Lena RJ, Medeiros BC, Blake N, Doykan C, Elashoff M, Cardone MH and Walter RB. Mcl1 dependence predicts response to vorinostat and gemtuzumab ozogamicin in acute myeloid leukemia. Leuk Res. 2014; 38(5):564-568.
• 31. Thompson RC, Vardinogiannis I and Gilmore TD. The sensitivity of diffuse large B-cell lymphoma cell lines to histone deacetylase inhibitor-induced apoptosis is modulated by BCL-2 family protein activity. PLoS One. 2013; 8(5):e62822. [PubMed] https://doi.org/10.1371/journal.pone.0062822.
• 32. Ierano C, Chakraborty AR, Nicolae A, Bahr JC, Zhan Z, Pittaluga S, Bates SE and Robey RW. Loss of the proteins Bak and Bax prevents apoptosis mediated by histone deacetylase inhibitors. Cell Cycle. 2013; 12(17):2829-2838. [PubMed] https://doi.org/10.4161/cc.25914.
• 33. Xargay-Torrent S, Lopez-Guerra M, Saborit-Villarroya I, Rosich L, Campo E, Roue G and Colomer D. Vorinostatinduced apoptosis in mantle cell lymphoma is mediated by acetylation of proapoptotic BH3-only gene promoters. Clin Cancer Res. 2011; 17(12):3956-3968. [PubMed]
• 34. Berghauser Pont LM, Naipal, K., Kloezeman, J.J., Venkatesan, S., Van den Bent, M., Van Gent, D.C., Dirven, C.M.F., Kanaar, R., Lamfers, M.L.M., Leenstra, S. DNA damage response and anti-apoptotic proteins predict radiosensitization by HDAC inhibitors in patient-derived glioblastoma cells. Cancer Lett. 2014; Oct. 8;doi 10.1016/j. canlet.2014.09.049. [PubMed] https://doi.org/10.1016/j.
• 35. Chen S, Dai Y, Pei XY and Grant S. Bim upregulation by histone deacetylase inhibitors mediates interactions with the Bcl-2 antagonist ABT-737: evidence for distinct roles for Bcl-2, Bcl-xL, and Mcl-1. Mol Cell Biol. 2009; 29(23):6149-6169. [PubMed] https://doi.org/10.1128/MCB.01481-08.
• 36. Streffer JR, Rimner A, Rieger J, Naumann U, Rodemann HP and Weller M. BCL-2 family proteins modulate radiosensitivity in human malignant glioma cells. J Neurooncol. 2002; 56(1):43-49. [PubMed]
• 37. Gratas C, Sery Q, Rabe M, Oliver L and Vallette FM. Bak and Mcl-1 are essential for Temozolomide induced cell death in human glioma. Oncotarget. 2014. [PubMed] https://doi.org/10.18632/oncotarget.1642.
• 38. Davids MS and Letai A. ABT-199: taking dead aim at BCL-2. Cancer Cell. 2013; 23(2):139-141. [PubMed] https://doi.org/10.1016/j.ccr.2013.01.018.
• 39. Bishton MJ, Harrison SJ, Martin BP, McLaughlin N, James C, Josefsson EC, Henley KJ, Kile BT, Prince HM and Johnstone RW. Deciphering the molecular and biologic processes that mediate histone deacetylase inhibitorinduced thrombocytopenia. Blood. 2011; 117(13):36583668. [PubMed]
• 40. Chou TC and Talalay P. Quantitative analysis of dose-effect relationships: the combined effects of multiple drugs or enzyme inhibitors. Advances in enzyme regulation. 1984; 22:27-55. [PubMed]
• 41. Klipper-Aurbach Y, Wasserman M, Braunspiegel-Weintrob N, Borstein D, Peleg S, Assa S, Karp M, Benjamini Y, Hochberg Y and Laron Z. Mathematical formulae for the prediction of the residual beta cell function during the first two years of disease in children and adolescents with insulin-dependent diabetes mellitus. Medical hypotheses. 1995; 45(5):486-490. [PubMed]
• 42. Esteller M, Garcia-Foncillas J, Andion E, Goodman SN, Hidalgo OF, Vanaclocha V, Baylin SB and Herman JG. Inactivation of the DNA-repair gene MGMT and the clinical response of gliomas to alkylating agents. The New England journal of medicine. 2000; 343(19):1350-1354. [PubMed]
• 43. Mollemann M, Wolter M, Felsberg J, Collins VP and Reifenberger G. Frequent promoter hypermethylation and low expression of the MGMT gene in oligodendroglial tumors. Int J Cancer. 2005; 113(3):379-385. [PubMed]
• 44. Chou TC. Preclinical versus clinical drug combination studies. Leuk Lymphoma. 2008; 49(11):2059-2080. [PubMed]
